Genius GP2 2000 - 800W Windlass for 12V Systems with 08 mm gypsy

Quick

Recommended Retail Price
£1,500.35 Inc. VAT

Online Price (inc. VAT)
£1,332.00

Part Number: FSGP22012008A00
Out Of Stock - Available to Back Order ONLY - Lead Times May Vary.

  • Description
  • Ask a Question
  • Reviews
  • Delivery
  • Returns

Quick

  • Horizontal on-deck windlasses
  • Anodized alluminium in hard oxide base
  • White composite material base (GP2 500)
  • Rope and chain on a single gypsy
  • Integrated sensor and magnet for chain counter
  • Available with manual Free-Fall system (GP2 500 only manual)
  • Supplied with pressure lever
  • IP66 watertight motor
  • Epicyclical gearbox (GP2 1500-2000)
GP2 FF - Automatic Free-Fall System
The Free-Fall technology applied to the Genius windlass allows free running of chain through the gypsy when lowering the anchor; simply by depressing the down control button the windlass will release its clutch and the gypsy will freewheel. To stop the Free-Fall depress the up control button on the windlass; the clutch will engage stopping the gypsy and allowing retrieval of the chain.
For boats from 6 to 12 meters (20 - 39 ft)
GP2 500 150 W 6 - 8 m 20 - 26 ft
GP2 1200 250 W 6 - 9 m 20 - 30 ft
GP2 1500 500 W 6 - 10 m 20 - 33 ft
GP2 2000 800 W 8 - 13 m 26 - 43 ft
GP2 500 GP2 1200FF GP2 1500-2000 GP2 1500-2000D
Available only in
composite material and without drum.
Available with (D) or without drum and in Free Fall (FF) version.
Windlasses are equipped with an epicyclical gearbox that provides much higher efficiency (+40% compared to equivalent traditional gearboxes).
Gypsy and Drum Ø 105 mm / 4" 9/64
GYPSY 6 mm 7 mm - 1/4" 8 mm 5/16"
CHAIN 6 mm 6 mm 7 mm 7 mm 1/4" 1/4" 8 mm 8 mm 5/16"
DIN 766 ISO DIN 766 ISO G4 BBB DIN 766 ISO G4
ROPE 1/2" (12,7 mm)
The values in the table refer to a three-strand polyester rope with a rope/chain splice manufactured with the Quick® system.

Supplied accessories standard


Contactor units Nylon handle
Models T6411-12 T6415-12  T6415-24
GP2 500 12 V
GP2 1200 12 V
GP2 1500   12 V
GP2 2000   12 V 24 V

Optional accessories

Platform for GP2 1500 - 2000 (H 40 mm)

Hydraulic magnetic
circuit breaker
UP/DOWN
control board
Foot
Switches
handheld
remote control
Chain
counters
Radio remote
control
Standard version GP2 2000 / D - GP2 2000 FF
Motor power 800 W
Motor supply voltage 12 V 24 V
Maximum pull 900 Kg / 1984 lb
Maximum working load 350 Kg / 772 lb
Working load 120 Kg / 265 lb
Current absorption @ working load (1) 96 A 50 A
Maximum chain speed (2) 29,6 m/min / 97.1 ft/min
Maximum chain speed @ working load (2) 20 m/min
65.6 ft/min
20,1 m/min
65.9 ft/min
Weight without drum 10,2 Kg / 22.4 lb
Weight with drum 11,5 Kg / 25.3 lb
Weight with FF 10,9 Kg / 24 lb
1) After an initial period of use
2) Measurements taken with a gypsy for a 8 mm chain

Dimensions

Genius - GP2 - 2000/2000DGP2 1500 - 1500 D

Deck thickness:
20÷40 mm (25/32"÷1" 9/16)
On request, shaft and studs can be supplied for greater deck thicknesses.
Dimensions in mm (inch)

Supplied accessories standard


Contactor units Nylon handle
Models T6411-12 T6415-12  T6415-24
GP2 500 12 V
GP2 1200 12 V
GP2 1500   12 V
GP2 2000   12 V 24 V

Optional accessories

Platform for GP2 1500 - 2000 (H 40 mm)

Hydraulic magnetic
circuit breaker
UP/DOWN
control board
Foot
Switches
handheld
remote control
Chain
counters
Radio remote
control
